Optix MAG301RFDE | MSI eSport Gaming Monitor

Download Datasheet

• Key Specs
• Spec Table

• Panel Size	29.5"
  Aspect ratio	21:9
  Panel Resolution	2560 x 1080
  Refresh Rate	200Hz
  Response time	1ms GTG (min)
  Brightness	300 nits
  Contrast Ratio	1000:1
  Power consumption	32W
  Control	5-way OSD navigation joystick
  Dimension (W x H x D)	709.4 x 399.2 x 234 mm / 27.93 x 15.72 x 9.21 inch
  Product Dimension Without Stand (W x H x D)	709.4 x 326 x 60 mm / 27.93 x 12.83 x 2.36 inch
  Weight	7.25kg / 10.12kg 15.98lbs / 22.31lbs
  Pixel Pitch (H x V)	0.2697(H) x 0.2697(V)
  Viewing angle	178° (H) / 178° (V)
  Panel Type	Rapid IPS Panel
  DCR	100000000:1
  Active Display Area (mm)	690.432(H) x 291.276(V)
  Surface Treatment	Anti-glare
  Display Colors	1.07B (8bits + FRC)
  Video ports	1x DP (Supports 1080p@200Hz as specified in DisplayPort 1.2a) 2x HDMI (Supports 1080p@180Hz as specified in HDMI 1.4)
  USB ports	2x USB 2.0 Type A 1x USB 2.0 Type B
  Audio ports	1x Earphone out
  Kensington Lock	Yes
  VESA Mounting	100 x 100 mm
  Power Type	External Adaptor 19V 3.42A
  Power Input	100~240V, 50~60Hz
  Signal Frequency	60 to 250.7 KHz(H) 48 to 200 Hz(V)
  Adjustment (Tilt)	-5° ~ 20°
  Adjustment (Swivel)	-45° ~ 45°
  Adjustment (Height)	0 ~ 130mm
  Note	Display Port: 2560 x 1080 (Up to 200Hz) HDMI: 2560 x 1080 (Up to 180Hz) DCI-P3 and sRGB follow CIE1976 Standard
  DCI-P3 / sRGB	85% / 105%
  Frameless Design	Yes
  Carton Dimension (W X H X D)	940 x 485 x 165 mm / 37.01 x 19.09 x 6.50 inch
  DYNAMIC REFRESH RATE TECHNOLOGY	G-sync Compatible
  ACTIVATED RANGE	48 to 165Hz
  Compatibility	PC, Mac, PS5™, PS4™, Xbox, Mobile, Notebook * All trademarks and the registered trademarks are the property of their respective owners.
  Console Mode	2K Resolution PS5™ Optimization FHD @ 120Hz * All trademarks and the registered trademarks are the property of their respective owners.
